Laboratory Manual For Electronic Cırcuıts

ISBN :	9786054649297
Yazar :	Bülent Büyükgüzel
Yayıncı :	Akademisyen Kitabevi
Sayfa Sayısı :	310

Favorilerime Ekle Hata Bildir Tavsiye Et!

25,00 TL

Satışta değil

Telefon Kodu : 546847

Ürün Özellikleri

This laboratory manual is prepared for the students taking the electronic circuit courses which are EEE226 Electronic Circuits, EEE325 Linear Integrated Circuits, and EEE328 Digital Electronics, offered in the Electrical and Electronics Engineering Department at çukurova University. The content covers the course materials taught in the department. The manual is mainly intended to verify theory taught in the electronic courses in the laboratory. This manual is divided into four parts as follows: Section 1 introduces the laboratory rules, simulation of electronic circuits and laboratory equipments (Oscilloscope, DC Power Supply, DMM, and Signal Generator) to be used in the experiments. Section 2 is devoted to experiments involving the basic electronic circuits which are taught in EEE226. It contains nine experiments, and it starts with basic measurements and learning the equipments used in Electronic Laboratory. The following three experiments are subjected on the diode characteristic and circuits. The next four experiments are on transistor characteristics and basic BJT and FET transistor based amplifiers. The last experiment is subjected on frequency response of the basic amplifiers. Section 3 is devoted to experiments involving the analog electronic circuits which are taught in EEE325. It contains nine experiments, and it starts with current mirror circuit and active loads. The following two experiments are subjected on basic BJT and MOS differential amplifiers. The next four experiments are subjected on op-amp parameters and circuits such as amplifiers, precision rectifiers, and integrator circuits. The last two experiments are subjected on power amplifiers and voltage regulators, respectively. Section 4 is devoted to experiments involving the digital electronic circuits which are taught in EEE328. It contains eight experiments, and it starts with logic voltage level of gates. The following three experiments are subjected on basic gates (RTL, DTL, TTL, MOS) and its characteristics. The last four experiments are subjected on multivibrator circuits such as bistable, monostable, and astable. Each experiment contains the following parts: Objective: The purpose of the experiment is given. Theory: The complementary information about the theory related to the experiment. Preliminary: Detailed analysis of the experiment and should be completed before coming to the laboratory. Experimental Procedure: Containing a relatively structured set of steps for performing the experiment. Conclusion: This section is included for the evaluation of the differences between the theoretical and experimental results. Equipment List: Lists of components and standard equipments which DMM, Oscilloscope, signal generator, and a prototyping board. Appendix includes the data sheets for the components used in the experiments.
